The LG 75UH5Q is a 75-inch UHD signage display with 500-nit typical brightness, webOS 8.0 and LG Shield security. Its 24/7 operation, landscape and portrait support, and built-in Wi-Fi and Bluetooth suit commercial information and promotional displays.
Select a thumbnail or swipe. Select the main image to view full size.
LG
Model: LG 75UH5Q
Series: UH5Q · Screen size: 75"
S$3,111.95
75-inch UHD signage with LG webOS and LG Shield security.
The LG 75UH5Q is a 75-inch UHD signage display with 500-nit typical brightness, webOS 8.0 and LG Shield security. Its 24/7 operation, landscape and portrait support, and built-in Wi-Fi and Bluetooth suit commercial information and promotional displays.
A 75-inch UHD signage display combining the LG webOS platform with LG Shield security for commercial content presentation.
UHD resolution presents detailed content, while the wide viewing angle helps keep information visible from different positions.
The integrated system-on-chip supports multiple tasks without a separate media player. The webOS platform provides an intuitive interface, app development tools and webOS partner apps.
Partial conformal coating on the power board helps protect against salt, dust, iron powder and humidity. IP5X protection and Shock Monitoring support reliability. When a physical impact occurs, the media controller can alert the administrator.
LG Shield uses five independent defence layers covering the server, application, operating system, system and hardware. LG also states that the webOS platform supports ETSI EN 303 645.
Compatible SuperSign solutions support the creation and management of digital signage content. Available options include SuperSign Cloud. SuperSign software must be purchased separately.
| Screen Size | 75" |
|---|---|
| Panel Technology | ADS |
| Back Light Type | Edge |
| Aspect Ratio | 16:9 |
| Native Resolution | 3,840 x 2,160 (4K UHD) |
| Refresh Rate | 60 Hz |
| Brightness | 500 nit (Typ.) |
| Contrast Ratio | 1,200 : 1 (Typ.) |
| Dynamic CR | 1,000,000 : 1 |
| Color gamut | BT709 95% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 1.07G (8bits + FRC) |
| Response Time | 8ms (G to G) |
| Surface Treatment (Haze) | 25% (Typ.) |
| Life Time (Min.) | 50,000 Hrs |
| Operation Hours (Hours / Days) | 24 / 7 |
| Portrait / Landscape | Yes / Yes |
| Bezel Color | Black |
|---|---|
| Bezel Width | 12.9 mm (Even) |
| Weight (Head) | 35.7 kg |
| Packed Weight | 44 kg |
| Monitor Dimensions (W × H × D) | 1,679.5 × 958.7 × 29.7 mm (without IR, Handle) |
| Carton Dimensions (W × H × D) | 1,820 × 1,115 × 200 mm |
| Handle | Yes |
| VESA™ Standard Mount Interface | 600 × 400 mm |
| Supported features | Internal Memory 16 GB, Wi-Fi & Bluetooth (Built-in), Temperature Sensor, Auto Brightness Sensor (IR/Light sensor receiver), Acceleration (Gyro) Sensor, Local Key Operation, webOS 8.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Booting Logo Image, No Signal Image, RS-232C Sync, Local Network Sync, PIP, PBP (4 (Support Only One External Input)), Screen Share, Video Tag (4 (Support Only One External Input)), Play via URL, Screen Rotation, External Input Rotation, Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Cisco Certification (TBD), Crestron Connected, Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom |
|---|
| Operation Temperature | 0 °C to 40 °C |
|---|---|
| Operation Humidity | 10 % to 80 % |
| Power Supply | AC 100-240 V ~, 50/60 Hz |
|---|---|
| Power Type | Built-In Power |
| Typ. | 162 W |
|---|---|
| Max. | 243 W |
| Smart Energy Saving (70%) | 113W |
| DPM | 0.5 W |
| Power off | 0.5 W |
| BTU (British Thermal Unit) | 553 BTU/Hr(Typ.), 830 BTU/Hr(Max.) |
| Safety | CB / NRTL |
|---|---|
| EMC | FCC Class "B" / CE / KC |
| ePEAT(US only) | Yes (Carbon "Reducing CO2") (TBD) |
| ErP / Energy Star | No / Yes |
| OPS Type Compatible | No |
|---|---|
| OPS Power Built In | No |
| SuperSign CMS | Yes |
|---|---|
| SuperSign Control+ | Yes |
| SuperSign WB | Yes |
| SuperSign Cloud | Yes |
| LG ConnectedCare | Yes |
| Mobile CMS | Yes |
| Input | HDMI (3, 3840x2160@60Hz, HDCP 2.2/1.4), DP (3840x2160@60Hz, HDCP 2.2/1.4), RS-232C (4 Pin Phone-Jack), RJ45 (LAN), IR, USB 2.0 Type A (2) |
|---|---|
| Output | Audio, RS-232C (4 Pin Phone-Jack), IR (No (Support IR Daisy Chain via RS232C In/Out)) |
| Speaker | 10 W × 2 |
|---|
| Supported languages | English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic, Polski |
|---|
| Basic | Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6ea) |
|---|---|
| Optional | Normal Wall Mount (LSW640A/B) |
| IP Rating | IP5X |
|---|---|
| Conformal Coating (Power Board) | Yes (Partial Space Coating) |
Source: the supplied LG global 75UH5Q-E product page. Specifications may vary by region. Cisco Certification and ePEAT entries are marked TBD by LG; they are not presented as confirmed certifications.
